Tonearm lift inox

adjustable in height

Tonearm lift steel inox made in italy adjustable in height

Diameter 12.90 mm

We are proud to introduce a new arm lifter, entirely designed and made in Italy by Audiosilente.

Made of stainless steel, available diameter 12.90mm .

Any diameter in the range of 11.50mm to 13.90mm can also be supplied upon request.

The arm lifter has a total height of 29 mm including the thickness of the arm rest, the useful size for the excursion of the fixing bracket is 15 mm + the thickness of the bow of 5 mm.
Other new features are:
1 basic adjustment of the central piston (+4.5 mm).
The brass inner central body has 3 threaded holes with relative grub screws, through which it is possible to adjust the height of the stainless steel central pin (central piston), which has a maximum adjustment of +4.5 mm from the standard height (29 mm). This is useful when the arm lift support bracket is far from the arm tube and therefore it is needed an arm lifter with an arm rest positioned higher (+4.5 mm max ) than common arm lifters found on the market.
2 fine adjustment during music playback ( 1.3 mm = 5 mm )
The central pin (central piston) supporting the arm rest has a threaded upper hole with a slotted head machine screw, as standard the screw is totally screwed in. By slightly loosening the lateral grub screw of the arm rest it is possible to undo the upper screw for a total of 2.5 turns resulting in a maximum excursion of about + 1.3 mm. This way it’s possible to adjust the height of the central piston and therefore the height of the cartridge with respect to the vinyl. 1.3 mm of arm rest height is equivalent to about 5 mm of adjustment of the cartridge
3 fine adjustment of the arm rest
The stainless steel upper arm rest has a side hole with relative metal grub screw, by loosening which it is possible to rotate the arm rest to the preferred position.
ALL Made in Italy by Audiosilente
